Automated Guided Vehicles

  • Share:

Automating a Solution to Today's Labor Shortage

From skilled to reliable, permanent or seasonal, labor is becoming increasingly hard to find and difficult to afford. Automation is becoming an inevitable and invaluable option for warehousing, manufacturing and distribution operations.

Find the Right Automated Lift Truck for Your Application

3030

Raymond Courier Automated Stacker

  • Ideal for pick-up and drop-off, end-of-aisle, end-of-line and conveyor picking applications
  • Lift height to 72” / 2,500 lb. capacity
  • Reverse motion and obstruction sensor, auto pallet engagement (options)

3220

Raymond Courier Automated Tow Tractor

  • Ideal for pulling carts or trailers with heavy loads on flat ground or ramps in batch picking, parts-to-line and end-of-line (automated conveyor cart) applications; and can operate under low hanging structures.
  • 15,000 lb. capacity
  • Low Clearance arch standard
  • Dual slots for hitch height adjustment (optional)

3020

Raymond Courier Automated Tow Tractor

  • Ideal for pulling cart or trailer loads in batch picking, parts-to-line and end-of-line (automated conveyor cart) applications
  • 10,000 lb. capacity
  • Low clearance arch option
  • Automatic hitch and unhitch with dual slots for hitch height adjustment (optional)
automated tow tractor, raymond courier, 3020

3010

Raymond Courier Automated Pallet Truck

  • Ideal for transporting pallets over long hauls, for put-aways, cross-docking and load staging applications
  • 8,000 lb. capacity
  • Reverse motion and obstruction sensor, double length fork (options)
automated pallet truck, raymond courier, 3010

Use the tables below to find the right Raymond Courier Truck for your application:

  • Warehousing 3030 3220 3020 3010
    Inbound Staging to Putaway
    (floor to rack storage up to 72")    		 x
    Staging to Pick & Drop Location x x x x
    Crossdock (staging to staging) x x x x
    Material
    Movement    		 Pallets from Pick & Drop to
    Outbound Staging    		 x x x x
    Towing Capacity
    <10,000 lbs    		 x x
    Trash/Dunnage Transport x x x
    Outbound Pallet Picking (floor storage) x
    Layer picking to Outbound Staging x
    Order Pallets/Carts to Pack-Out x x x x
    Pallets to Wrapper/Wrapper to Outbound Staging x x x

  • Manufacturing 3030 3220 3020 3010
    Inbound Staging to Putaway
    (floor to rack storage up to 72")    		 x
    Staging to Pick & Drop Location x x x x
    Material
    Movement    		 Kitted Parts-to-Line x x
    Bulk Parts-to-Line x x x x
    Small Parts-to-Line x x
    Towing Capacity
    <10,000 lbs    		 x x
    Sub-Assembly to Assembly Line x x
    Empty Container Management x x x x
    Trash/Dunnage Transport x x x x
    Outbound Finished Goods to Warehouse x x x x
    Finished Goods to Outbound x x x x

Real World Solutions. Change The Way You Do Business.
